K10(14)/5-B Hexagonal-crimping-die (twofold)
| Shape: | Block (B) |
|---|---|
| Crimping contour: | Hexagon to DIN 48083 |
| Index: | 10 + 14 |
| Crimping width: | 5 mm |
Product number:
76900018
Block press inserts
K10(14)/5-B Hexagonal-crimping-die (twofold)
Applications
K10: 25 mm2 copper non tension and full tension, as well as 10 mm2 aluminium non tension.
K14: 50 mm2 copper non tension and full tension, as well as 35 mm2 aluminium non tension and full tension. 35/6 mm2 Al-sleeve (ACSR).
K14: 50 mm2 copper non tension and full tension, as well as 35 mm2 aluminium non tension and full tension. 35/6 mm2 Al-sleeve (ACSR).
| Shape: | Block (B) |
|---|---|
| Suitable for: | crimping cable lugs, connectors, Al-sleeves |
| Crimping contour: | Hexagon to DIN 48083 |
| Index: | 10 + 14 |
| Crimping width: | 5 mm |
Included in delivery:
Options
