HOLGER CLASEN DW40/160 Angle drilling machine with Keyed chuck 1 - 10 mm
| Power [W]: | 400 W |
|---|---|
| Speed: | 1200 min-1 |
| Chuck: | Keyed chuck (1/2" x 20 UNF) |
| Clamping Range Ø: | 1 - 10 mm |
| Current: | Pneumatic |
Product number:
44107000
Ölfreier Betrieb möglich
DW40/160 Angle drilling machine with Keyed chuck 1 - 10 mm
Applications
Pneumatic angle drilling machine for work in hard-to-reach places. The angle drilling machine is used in all industrial areas as well as workshops and plant repairs.
Air angle drilling machine for industrial applications
Reliable pneumatic drilling machine with excellent power to weight ratio.Small head dimension allows working in narrow spaces.
Special chuck for pneumatic tools and high-precise collet chucks provide efficient use.
Long tool life at high power.
The angle drilling machine has a 90 degree angle head, suitable for your application.
| Power [W]: | 400 W |
|---|---|
| Speed: | 1200 min-1 |
| Chuck: | Keyed chuck (1/2" x 20 UNF) |
| Clamping Range Ø: | 1 - 10 mm |
| Construction form: | Angle head 90° |
| Start: | Valve lever |
| Direction of rotation: | Right |
| Weight: | 1.7 kg |
| Housing Ø: | 46 mm |
| Length: | 320 mm |
| Height: | 103 mm |
| Inlet air connection: | G 1/4" |
| Recommended hose Ø: | 9 mm |
| Air consumption: | 10 l/s |
| Vibration: | < 2.5 m/s² |
| Sound pressure level: | 80 dB(A) |
| Current: | Pneumatic |
| Working pressure: | 6.3 bar |
Included in delivery:
Tool, quick-coupling nipple, assembly wrench.
