K18/7-FG Hexagonal-crimping-die
| Shape: | Spring large (FG) |
|---|---|
| Crimping contour: | Hexagon to DIN 48083 |
| Index: | 18 |
| Crimping width: | 7 mm |
Product number:
76900344
Spring clip press inserts
K18/7-FG Hexagonal-crimping-die
Applications
K18: 95 mm2 copper non tension, as well as 70 mm2 aluminium non tension and full tension. 70/12 mm2 Al-sleeve (ACSR).
| Shape: | Spring large (FG) |
|---|---|
| Suitable for: | crimping cable lugs, connectors, Al-sleeves |
| Crimping contour: | Hexagon to DIN 48083 |
| Index: | 18 |
| Crimping width: | 7 mm |
Included in delivery:
Options
