MD410/900-LK115 Double rotor air motor
| Power [kW]: | 4.10 kW |
|---|---|
| Useful speed: | 0 - 9000 min-1 |
| Direction of rotation: | Reversible |
| Chuck: | Shaft-hub-connection Ø 19 j6 |
| Current: | Pneumatic |
Product number:
54328600
High tool life
MD410/900-LK115 Double rotor air motor
Applications
Air motors with double rotors (gear wheels) - drive technology intended to be assembled into other machines. These air motors are high operating safe, sturdy and direction of rotation is returnable.
Double rotor motor - rotation right/left drive - with 4.1 kW power
Useful Speed: 0 - 9,000 min-1Convincing through easy control and high starting safety
Operation in clockwise/counterclockwise rotation
Flexibility through optimum speed range
The air motor with double rotors impresses with its very long service life.
High starting torque
ATEX models II 2 GDcT4 - T6 or other special versions are available on request.
| Power [kW]: | 4.10 kW |
|---|---|
| Useful speed: | 0 - 9000 min-1 |
| Optimal speed: | 1100 - 5500 min-1 |
| Starting Torque: | 9.90 Nm |
| Direction of rotation: | Reversible |
| Chuck: | Shaft-hub-connection Ø 19 j6 |
| Construction form: | IEC-flange pitch circle 115 mm |
| Weight: | 9.00 kg |
| Length: | 181 mm |
| Housing Ø: | 140 mm |
| Shaft length: | 40 mm |
| Dimension A: | 115 mm |
| Min. Ø Inlet Air Motor / Pipe: | 18 / 19 mm |
| Min. Ø Exhaust Air Motor / Pipe: | 21 / 22 mm |
| Current: | Pneumatic |
| Max. Working pressure: | 6.0 bar |
| Inlet air connection: | G 1" (G 3/4") |
